Features
► The close coupled pumps are provided with internal mechanical shaft seal which can be replaced without
► disturbing pump or pipe connections.
► Heavy and robust design motor adapter provides a rigid connection between the pump casing & motor flange.
► Generous venting of seal chamber & liquid flushing at seal faces is provided by gland plate flush connections.
► The pump impellers are dynamically balanced to grade 6.3 of ISO 1940.
► Rigid volute casing with ribs integrally cast and provided with gauge, flush and drain connections.
► The pumps can be coupled with NEMAstandard motors suitable for Vertical application.
► Flow straightening vanes in suction area of pump casing ensures superior performance and quiet operation.
Flow range : Up to 9700 GPM
Head range : Up to 490 feet
Ambient temperature : Max. +140°F for Premium efficiency motors.
Applications
► Heating, Ventilation and Air-conditioning (HVAC)
► Pressure boosting
► Industrial applications
► Water supply
► Fire protection systems.
