Investment Cast Stainless Steel Submersible Pumps
Home / Product / Deep Well Submersible Pumps / Investment Cast Stainless Steel Submersible Pumps
Investment Cast Stainless Steel Submersible Pumps
Investment Cast Stainless Steel Submersible Pumps
- Pump Size: 8” & 10″
- Flow Ratings : 250, 375, 500 & 650 GPM
- Maximum Head: Up to 2500 feet
- Pump Rating: 15 HP to 125 HP
- Liquid Temperature: 113°F
- Max. Sand Content: 50 ppm
- Also Available Under Built Program
- All pumps have been designed using computational fluid dynamics to ensure maximum efficiency.
- All pumps are designed using materials suitable for working with sand found in deep wells.
- All journal bearings and impeller wear rings are made of nitrile rubber to ensure consistent performance over a longer period.
- All pumps are provided with upthrust bearings to control axial movement of the impeller assembly during transportation and start-ups.
- To prevent water hammer when the pump is stopped, all pumps are provided with a non-return valve.
- Agriculture & Irrigation
- Municipal water supply
- Industrial water supply
